Shenzhen Chuangxintong Technology Development Co., Ltd. introduces product cases, including project product introduction, project background, project analysis, product function introduction, etc., as follows:
Project product: Sharp-angle wing gate dual channel
Turnstile gate |Flap turnstile |Outdoor turnstiles|Outdoor turnstile |Turnstile technology | Flap barrier gate |Revolving gate|Flap barrier | Turnstile suppliers
Puerta de torniquete | Torniquete de aleta | Torniquete de exterior | Torniquete de exterior | Tecnología de torniquetes | Puerta de barrera de aleta | Puerta giratoria | Barrera de aleta | Proveedores de torniquetes
Sharp-angle wing gate dual channel
Project background:
Anhui Wuhu Century Star Ice Skating Rink is located on the 4th floor of Liansheng Commercial Plaza, No. 17, Zheshan Middle Road, Jinghu District, Wuhu City, Anhui Province, and its headquarters is located in Beijing. It has successively won the honors of "National Youth Sports Club", "National Figure Skating Grade Test System Promotion Unit", and "Ice Project Back Talent Training Base". Chuangxintong Technology developed a one-card access control system at its request, using our sharp-angle wing gate dual channel products.
Project analysis:
According to customer needs and actual site conditions, this project uses a two-in and two-out sharp-angle soft wing gate. Among them, we designed an iron door for it, which can be opened for special circumstances. The beautiful use of wing gates is used in major image-oriented occasions, such as subways, buildings, banks, etc. The variety and quality of wing gates require perfect design. The cost performance of the wing gate is more worthy of attention.
Actual application diagram of the double-channel wing gate with sharp angle
< Actual application diagram of the double-channel wing gate with sharp angle>
Brief description of the functions of the innovative wing gate with sharp angle:
It has the function of self-checking and alarm prompting, which is convenient for users to maintain and use.
It can be connected to the control signal or button or remote control output by any control device to realize single and two-way control of passage.
Automatic reset function: After each 90-degree extension and detection of people and objects passing through, it will automatically reset, or if it does not pass within the specified time (delay is adjustable in multiple gears), the system will automatically cancel the permission for this passage and return to the initial position.
Light indication: High-brightness traffic light status indication, guiding passage.
Anti-tailgating function:
1. When the person or object in front passes through, during the process of resetting the swing wing, if someone follows or rushes through the gate, an alarm will be issued.
2. (When equipped with infrared detection) When the person or object in front has not passed completely, if someone follows and breaks in, the infrared will start the alarm.
3. When someone swipes the card in the forward direction and someone breaks in in the reverse direction, the swing wing will close. When the person or object exits, the swing wing will open again to allow forward passage.
Fire input: It can be connected to the fire alarm signal to achieve uninterrupted power supply and normal opening.
Alarm prompt function: When illegal passage or gate rushing occurs, an alarm prompt will be automatically issued.
Adjustable speed: The speed of opening and closing of the swing wing can be adjusted in 8 gears, and the user can set it according to actual needs.
Automatic protection function: When external force prevents the normal movement of the swing wing, and the external force is continuous, the system will automatically detect 5 times and then automatically protect and enter the dormant state. When the next legal signal is input, the gate will automatically return to normal.
Anti-collision buffer function: When illegal passage or forced tailgating occurs, when someone or an object blocks the swing wing, humanized injury prevention is achieved. It also greatly reduces mechanical damage caused by collision.
Unattended: The swing wing is automatically opened when the power is off, and automatically resets when the power is on (blocking passage).
Fast and silent: electric power assistance, zero mechanical wear. About 45-60 people/minute
Expandable functions of the double-channel wing gate with sharp angle:
1. Remote control and management through the management computer (command docking is required).
2. Counting function to realize the number of people present and ensure accurate counting after people pass through.
3. Personalized voice prompt function makes the channel closer to life.
Actual picture of the double-channel wing gate with sharp angle
Technical parameters of the double-channel wing gate with sharp angle:
Shell material: SUS304 stainless steel
Specification size: 1200*300*1000MM
Weight: about 70KG.
Swing type: 260mm (standard) acrylic.
Opening and closing speed: 0.8-2S.
Motor: 24V /30W DC.
Positioning accuracy: 120 degrees photoelectric positioning.
Adaptable temperature: -40℃～ 80℃.
Humidity: 5% - 90%.
Reset delay time: 3S, 5S, 10S, 20S adjustable.
Traffic speed: about 45-60 people/minute.
Shell processing technology: laser, bending, cutting, welding, polishing, grinding and other processes.
Working environment: indoor and outdoor.
